SRUPCBD40

Small Round PCB UHF Anti Metal RFID Tags​

Small round PCB UHF anti-metal RFID tags are ultra-compact, rugged RFID identifiers designed specifically for metallic environments. Built using FR4 or ceramic-based printed circuit boards, these tags feature a tuned antenna structure and integrated isolation layer, enabling reliable performance even when affixed directly to metal.

With diameters as small as 10mm–25mm, they are ideal for tagging tools, surgical instruments, metal components, and IT equipment where space is tight and read performance must not be compromised.

Technical Highlights:

  • UHF frequency: 860–960 MHz (EPC Gen2 / ISO 18000-6C compliant)

  • Optimized for on-metal performance

  • Constructed from durable PCB substrates (FR4/ceramic)

  • Read range: Up to 1–3 meters (depending on size and reader)

  • Diameter: Typically 10mm–25mm; custom sizes available

  • Mounting: Adhesive, rivet, or embedded into metal fixtures

  • Operating temperature: -40°C to +150°C

INQUIRY
INQUIRY
Datasheet
Physical Specification
Item
SRUPCBD40
Tag size
D40 mm
Thickness
3 mm
Material
PCB
Adhesive
3M 300LSE
Color
White, Black, etc.
Weight
1.2 g
RFID Specification
Air Interface Protocol
ISO/IEC 18000-6C, EPCglobal Class 1 Gen 2
Operating Frequency
902-928 MHz (US), 865-868 MHz (EU)
IC Type
NXP UCODE 8, Alien Higgs 3, Alien Higgs 9
Memory
UCODE 8: EPC-128 bits; User-N/A; TID-96 bits
, Higgs 3: EPC-96(up to 480) bits; User-512 bits; TID-64 bits, Higgs 9: EPC-96(up to 496) bits; User- up to 688 bits; TID-48 bits
Write Endurance
100,000 cycles
Data Retention
Up to 20 years
Read Range
(Fixed Reader)
680 cm, (US) 902-928MHz, On Metal
650 cm, (EU) 865-868MHz, On Metal
Read Range
Handheld Reader
350 cm, (US) 902-928MHz, On Metal
350 cm, (EU) 865-868MHz, On Metal
Feature
Workable on metal surface
Environmental Specification
Operating Temperature
-40 °C to +150 °C / -40 °F to +302 °F
Recommended Storage
+25°C / 77°F, 40% RH
Shelf Life
2 years at +25°C / +77°F, 40% RH
IP Rating
IP68
Other Specification
Installation
Screw or backing adhesive
Package Detail
50 pcs/ESD bag or customized
Delivery Format
Single unit
Samples Policy
For free if stock available
Personalization
Pre-print Logo / Barcode / QR / Series number, Pre-encode / encrypt, etc.
Final Inspection
100% tested
Certification
CE Approved, RoHs Approved, Reach Approved, etc.
Application
Military Armories Tracking, Police Stations & Tactical Units Management, Private Security Firms Equipment, etc.
